Staircase switch CRM-47 230 002470304
Specifications
- ETI Code:
- 002470304
- Description:
- CRM-47 230
- Class name:
- Staircase switch
- Maximum load capacity at AC1 (VA):
- 4000VA
- Number of CO contacts:
- 1
- Function:
- Time relay
- Supply voltage (V):
- 230V
- Number of contacts:
- 1
- Rated current (A):
- 16A
- Voltage type:
- AC
- Category:
- Twillight and staircase switches
Documents
Logistic Data
Product
- Net weight of the product
- 0.07 kg
- Customs tariff
- 85364900
- logis_net_width
- 18 mm
- logis_net_height
- 93 mm
- logis_net_depth
- 65 mm
Basic packaging
- EAN code for a basic packaging
- 3838400117090
- Basic packaging weight
- 0.07 kg
Transport packaging
- Transport packaging quantity
- 10
- EAN code for a transport packaging
- 3838400117083
- Transport packaging weight
- 0.756 kg
- Pallet quantity
- 3640
ETIM Clasification
- Classification
- EC000297
- Class name
- Staircase lighting timer
- Function
- Electronic with multi function
- Mounting method
- DIN rail
- Width in number of modular spacings
- 1
- Built-in depth
- 68mm
- Control voltage 1
- 230…230V
- Frequency control voltage 1
- 50…50Hz
- Rated switch current
- 16A
- Voltage type (supply voltage)
- AC
CRM-47 230
