Twilight switch PZS 002471103
Specifications
- ETI Code:
- 002471103
- Description:
- PZS
- Class name:
- Twilight switch
- Maximum load capacity at AC1 (VA):
- 4000VA
- Number of NO contacts:
- 2
- Function:
- Monitoring and Control relays
- Supply voltage (V):
- 180V-230V
- Luminous flux (Lx):
- 2lx-50lx
- Number of contacts:
- 1
- Rated current (A):
- 16A
- Voltage type:
- AC
- Category:
- Twillight and staircase switches
Documents
Logistic Data
Product
- Net weight of the product
- 0.065 kg
- Customs tariff
- 85364900
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895340164
- Basic packaging weight
- 0.71 kg
Transport packaging
- Transport packaging quantity
- 6
- EAN code for a transport packaging
- 3838895792291
- Transport packaging weight
- 0.426 kg
- Pallet quantity
- 18000
Intermediate packaging
- qty
- 1 pcs
- Weight
- 0.07 kg
- volume
- 0.1 dm3
ETIM Clasification
- Classification
- EC001645
- Class name
- Twilight switch for distribution board
- Rated voltage
- 230V
- Rated frequency
- 50…50Hz
- Rated switch current
- 16A
- Adjustment range brightness value
- 2…200lx
- Mounting method light sensor
- Built-in
- Mounting method
- DIN rail
- Width in number of modular spacings
- 1
- Built-in depth
- 68mm
- Degree of protection (IP)
- IP20
- Degree of protection (IP) light sensor
- IP65
PZS
