Fuse - base SET EZR 63/GEG 63 3p 002323111
Specifications
- ETI Code:
- 002323111
- Description:
- SET EZR 63/GEG 63 3p
- Class name:
- Fuse - base
- sort_order:
- 2
- id_level1:
- 1264
- l1_sort_order:
- 2755
- l2_sort_order:
- 2791
- l3_sort_order:
- 2819
- l4_sort_order:
- 2820
- l5_sort_order:
- 2823
- l6_sort_order:
- 2824
- Mounting type:
- Busbar mounting
- Type:
- EZR/3
- Size:
- DII
- Dimensions:
- E27
- Number of poles:
- 3
- Rated current (A):
- 63
- Rated AC voltage (V):
- 500
- Connection:
- 2XM5
Documents
Logistic Data
Product
- Net weight of the product
- 0.402 kg
- Customs tariff
- 85389099
- logis_net_width
- 166 mm
- logis_net_height
- 65 mm
- logis_net_depth
- 48 mm
Transport packaging
- Transport packaging quantity
- 25
- EAN code for a transport packaging
- 3838895565796
- Transport packaging weight
- 11.62 kg
- Pallet quantity
- 600
ETIM Clasification
- Classification
- EC000094
- Class name
- D-system fuse base
- Number of knife blade fuse holders
- 3
- Max. rated operation voltage Ue AC
- 500
- Number of poles
- 3
- Construction size
- DII
- Material
- Porcelain
- Model
- Fitted screw
- Rated voltage
- 500V
- Rated current
- 63A
