Fuse link NHS1/110 gBat 40A/550V DC 004723269
Specifications
- ETI Code:
- 004723269
- Description:
- NHS1/110 gBat 40A/550V DC
- Class name:
- Fuse link
- Rated current (A):
- 40
- Type:
- NH-S110
- Size:
- NH1
- Characteristics:
- gBat
- Rated DC voltage (V):
- 550
- Dimensions:
- S110mm
- Indicator:
- Top fuse status indicator
- Breaking capacity DC (kA):
- 30
- Operating joule integral (A2s):
- 833
- L/R (ms):
- 3
- Prearcing joule integral (A2s):
- 250
- Application:
- Battery protection
- Power dissipation (W):
- 6
- Power dissipation (0,7x In) (W):
- 2,7
- Standards:
- IEC 60269-7
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895759089
- Net weight of the product
- 490 g
- Customs tariff
- 85361050
- logis_net_width
- 46 mm
- logis_net_height
- 139 mm
- logis_net_depth
- 50 mm
Level 1 Packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838895694106
- Basic packaging weight
- 1.36 kg
Level 2 Packaging
- Transport packaging quantity
- 24
- EAN code for a transport packaging
- 3838895694113
- Transport packaging weight
- 11.23 kg
- Pallet quantity
- 1248
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Rated voltage DC
- 550
- Application
- Battery protection
- Construction size
- NH1
- Rated current
- 40
- Rated voltage
- 550
- Voltage type
- DC
- Rated switching capacity
- 30
- Utilization category
- Other
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
