Fuse - base PK 1XL M10-M10 1500V 1p 004132017
Specifications
- ETI Code:
- 004132017
- Description:
- PK 1XL M10-M10 1500V 1p
- Class name:
- Fuse - base
- id_level1:
- 2579
- l1_sort_order:
- 5505
- l2_sort_order:
- 5869
- l3_sort_order:
- 5870
- l4_sort_order:
- 5871
- l5_sort_order:
- 5872
- l6_sort_order:
- 5873
- Rated current (A):
- 250
- Size:
- 1XL
- Rated AC voltage (V):
- 1500
- Rated DC voltage (V):
- 1500
- UL certificate:
- E356295
- Product group:
- LV-fuse base
- Connection:
- M10
- Mounting:
- Screw mounting
- Max. permissable power dissipation per fuse link (W):
- 32
- Standards:
- IEC 60269, UL 4248-1, UL 4248-19
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895985723
- Net weight of the product
- 675 g
- Customs tariff
- 85389099
- logis_net_width
- 56 mm
- logis_net_height
- 260 mm
- logis_net_depth
- 82 mm
Basic packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838895654810
- Basic packaging weight
- 2.125 kg
Transport packaging
- Transport packaging quantity
- 15
- EAN code for a transport packaging
- 3838895654827
- Transport packaging weight
- 11.25 kg
- Pallet quantity
- 270
ETIM Clasification
- Classification
- EC000067
- Class name
- Low Voltage HRC fuse base
- Rated voltage DC
- 1500
- Mounting method
- Screw mounting
- Max. rated operation voltage Ue AC
- 1500
- Construction size
- Other
- Number of poles
- 1
- Rated current
- 250A
