Fuse - base PKI 3L M12-M12 1500V 1p 004132024
Specifications
- ETI Code:
- 004132024
- Description:
- PKI 3L M12-M12 1500V 1p
- Class name:
- Fuse - base
- id_level1:
- 2579
- l1_sort_order:
- 5505
- l2_sort_order:
- 5869
- l3_sort_order:
- 5870
- l4_sort_order:
- 5877
- l5_sort_order:
- 5878
- l6_sort_order:
- 5881
- Rated current (A):
- 630
- Type:
- PKI
- Size:
- 3L
- Rated AC voltage (V):
- 1500
- Rated DC voltage (V):
- 1500
- Product group:
- LV-fuse base
- Connection:
- M12
Documents
Logistic Data
Product
- Net weight of the product
- 1.547 kg
- Customs tariff
- 85389099
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895672999
- Basic packaging weight
- 1.35 kg
Transport packaging
- Transport packaging quantity
- 10
- EAN code for a transport packaging
- 3838895673002
- Transport packaging weight
- 11.15 kg
- Pallet quantity
- 240
ETIM Clasification
- Classification
- EC000067
- Class name
- Low Voltage HRC fuse base
- Max. rated operation voltage Ue AC
- 1500
- Rated voltage DC
- 1500
- Construction size
- Other
- Number of poles
- 1
- Rated current
- 630A
PKI 3L M12-M12 1500V 1p
