Fuse link NHU01XL/150 aR 125A/1000V DC 004110813
Specifications
- ETI Code:
- 004110813
- Description:
- NHU01XL/150 aR 125A/1000V DC
- Class name:
- Fuse link
- Application:
- For protection on DC side of EV chargers
- Standards:
- IEC 60269-4
- Prearcing joule integral (A2s):
- 3300
- Power dissipation (0,7x In) (W):
- 12W
- Power dissipation (W):
- 31W
- Operating joule integral (A2s):
- 25000
- L/R (ms):
- 3ms
- Breaking capacity DC (kA):
- 30kA
- Indicator:
- Top fuse status indicator
- Type:
- NH-U
- Size:
- NH01XL
- Rated current (A):
- 125A
- Rated DC voltage (V):
- 1000V
- Characteristics:
- aR
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400101181
- Net weight of the product
- 450 g
- Customs tariff
- 85361090
- logis_net_width
- 29 mm
- logis_net_height
- 177 mm
- logis_net_depth
- 51 mm
Basic packaging
- Basic packaging quantity
- 3
- EAN code for a basic packaging
- 3838400101198
- Basic packaging weight
- 1.24 kg
Transport packaging
- Transport packaging quantity
- 30
- EAN code for a transport packaging
- 3838400101204
- Transport packaging weight
- 12.75 kg
- Pallet quantity
- 1560
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- Other
- Rated current
- 125
- Rated voltage
- 1000
- Voltage type
- DC
- Rated switching capacity
- 30
- Utilization category
- aR (accompanied semiconductor protection)
- Type of fuse status indicator
- Top fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
