Fuse link CH10x38gPV 2A 1000V UL 002625101
Specifications
- ETI Code:
- 002625101
- Description:
- CH10x38gPV 2A 1000V UL
- Class name:
- Fuse link
- sort_order:
- 1
- id_level1:
- 2579
- l1_sort_order:
- 5505
- l2_sort_order:
- 5506
- l3_sort_order:
- 5507
- l4_sort_order:
- 5508
- l5_sort_order:
- 5509
- l6_sort_order:
- 5510
- Type:
- CH
- Size:
- 10x38
- Rated current (A):
- 2
- Rated DC voltage (V):
- 1000
- Characteristics:
- gPV
- L/R (ms):
- 2
- Breaking capacity DC (kA):
- 10
- Application:
- For protection of photovoltaic modules
- Power dissipation (0,7x In) (W):
- 0,47
- Power dissipation (W):
- 1,12
- Operating joule integral (A2s):
- 2
- Prearcing joule integral (A2s):
- 2
- Standards:
- IEC 60269-6, UL 2579, UL 248-1
- UL certificate:
- E347771
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400055941
- Net weight of the product
- 8.3 g
- Customs tariff
- 85361010
- logis_net_width
- 10 mm
- logis_net_height
- 39 mm
- logis_net_depth
- 10 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895528678
- Basic packaging weight
- 0.08 kg
Transport packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895528685
- Transport packaging weight
- 4.1 kg
- Pallet quantity
- 84000
ETIM Clasification
- Classification
- EC002704
- Class name
- Cylindrical fuse
- Rated current
- 2
- Rated voltage DC
- 1000
- Application
- For protection of photovoltaic modules
- Construction size
- CH10
- Size
- 10x38 mm
- Rated voltage
- Other
- Utilization category
- Other
- Nominal current
- 2A
