Fuse link NHG2/M gPV 200A/1000V DC 004110346
Specifications
- ETI Code:
- 004110346
- Description:
- NHG2/M gPV 200A/1000V DC
- Class name:
- Fuse link
- Type:
- NH-G
- Size:
- NH2
- Rated current (A):
- 200A
- Rated DC voltage (V):
- 1000V
- Characteristics:
- gPV
- L/R (ms):
- 1ms
- Breaking capacity DC (kA):
- 30kA
- Application:
- Fuse link for DC application
- Indicator:
- Centre trip indicator for MK
- Power dissipation (W):
- 26W
- Power dissipation (0,7x In) (W):
- 11W
- Operating joule integral (A2s):
- 29000
- Prearcing joule integral (A2s):
- 4400
- Standards:
- IEC 60269-6
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400057334
- Net weight of the product
- 800 g
- Customs tariff
- 85361090
- logis_net_width
- 60 mm
- logis_net_height
- 75 mm
- logis_net_depth
- 60 mm
Basic packaging
- Basic packaging quantity
- 2
- EAN code for a basic packaging
- 3838895798842
- Basic packaging weight
- 1.5 kg
Transport packaging
- Transport packaging quantity
- 12
- EAN code for a transport packaging
- 3838895798859
- Transport packaging weight
- 9.8 kg
- Pallet quantity
- 624
ETIM Clasification
- Classification
- EC000055
- Class name
- Low Voltage HRC fuse
- Construction size
- NH2
- Rated current
- 200
- Rated voltage
- 1000
- Voltage type
- DC
- Rated switching capacity
- 30
- Utilization category
- gPV (photovoltaic protection)
- Type of fuse status indicator
- Centre fuse status indicator
- Insulated metal gripping lugs (IMGL)
- No
