Switch RBS220-10-12V AC 002464162
Specifications
- ETI Code:
- 002464162
- Description:
- RBS220-10-12V AC
- Class name:
- Switch
- Function:
- Bistable Switch RBS
- Supply voltage (V):
- 12V
- Rated operation current Ie at AC1 (A):
- 20A
- Voltage type:
- AC
- Number of NO contacts:
- 1
- Rated Frequency (Hz):
- 50Hz/60Hz
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400145697
- Net weight of the product
- 0.137 kg
- Customs tariff
- 85364900
- logis_net_width
- 35 mm
- logis_net_height
- 90 mm
- logis_net_depth
- 65 mm
Basic packaging
- Basic packaging quantity
- 8
- EAN code for a basic packaging
- 3838400101747
- Basic packaging weight
- 1.1 kg
Transport packaging
- Transport packaging quantity
- 96
- EAN code for a transport packaging
- 3838400101754
- Transport packaging weight
- 13.5 kg
- Pallet quantity
- 5664
RBS220-10-12V AC
